H3C LS-5570S-28S-HPWR-EI-A 28-Port Multi-Gig PoE++ Stackable Switch
H3C LS-5570S-28S-HPWR-EI-A 28-Port Multi-Gig PoE++ Stackable Switch

H3C LS-5570S-28S-HPWR-EI-A 28-Port Multi-Gig PoE++ Stackable Switch

H3C LS-5570S-28S-HPWR-EI-A is a high-performance Multi-Gigabit PoE++ switch featuring 28×2.5G/5G/10G ports (90W IEEE 802.3bt) and 4×25G uplinks, delivering ultra-low latency (≤5μs) for next-gen wireless and IoT deployments.

Place of Origin : China

Brand Name : H3C

Certification : CE, RoHS, FCC

Model Number : LS-5570S-28S-HPWR-EI-A

Port Configuration : 28×Multi-Gigabit PoE++ ports (2.5G/5G/10G, 90W IEEE 802.3bt) + 4×25G SFP28 uplinks

Switching Capacity : 336Gbps

Forwarding Rate : 252Mpps

Switching Latency : ≤5μs

Delivery Time : 2-7 working days

Product Details

H3C LS-5570S-28S-HPWR-EI-A High-Power 28-Port Multi-Gigabit Stackable Enterprise Switch

H3C LS-5570S-28S-HPWR-EI-A is an advanced Multi-Gigabit PoE++ switch engineered for next-generation enterprise networks. Featuring 28 Multi-Gigabit Ethernet ports (supporting 2.5G/5G/10G speeds) with high-power PoE++ (IEEE 802.3bt, up to 90W per port), it delivers superior performance for power-hungry devices while providing 4×25G SFP28 uplinks for high-speed backbone connectivity.

H3C LS-5570S-28S-HPWR-EI-A Next-generation 90W PoE++ Switch

LS-5570S-28S-HPWR-EI-A

H3C LS-5570S-54S-EI

H3C LS-5570S-28S-HPWR-EI-A  Specification

Product Model LS-5570S-28S-HPWR-EI-A
Port switch capacity(bps) 128G
System Switching Capacity(bps) 598Gbps
Flash 512M
CPU 1GHz, 2Cores

MAC address entries

32768
VLAN table 4094
VLAN interface 1022
IPv4 routing entries 12288

IPv4 ARP entries

8192

QOS forward queues

8

IPv6 ND entries 4096
Latency(64byte/us) GE port<5; 10GE port<3
Max Stacking Members

9

Max Stacking Bandwidth

80Gbps

MAX num in one link group 8
Origin China



Ultra-PoE Enabled: H3C LS-5570S-28S-HPWR-EI-A Enterprise Multi-Gigabit Switch

H3C LS-5570S-28S-HPWR-EI-A revolutionizes next-generation enterprise networking with carrier-class Multi-Gigabit performance, featuring 28×PoE++ ports (2.5G/5G/10G, 90W IEEE 802.3bt) and 4×25G SFP28 uplinks. Engineered for ultra-low latency (≤5μs) and intelligent power delivery, it provides deterministic connectivity for high-density PoE applications through hardware-accelerated forwarding and dynamic power management.



H3C LS-5570S-54S-EI



H3C LS-5570S-28S-HPWR-EI-A Application

H3C LS-5570S-28S-HPWR-EI-A is ideally deployed in high-density PoE++ environments requiring multi-gigabit speeds, including Wi-Fi 6E/7 wireless networks, 8K video surveillance systems, and advanced AV/VR installations. Its 28× multi-gig PoE++ ports (90W each) and 25G uplinks make it perfect for smart stadiums, digital healthcare campuses, and industrial IoT deployments where both high bandwidth and ultra-high power delivery are critical. The switch excels in conference centers, broadcast studios, and smart city infrastructure.



H3C LS-5570S-54S-EI



Abundant Security Features

Tianyida Electronic Industry Limited

About us

Tianyida Electronic Industry Limited specializes in business trade and technical services of Cisco switches, routers, optical modules, wireless access points, firewalls and other network equipment.

Our company is an authorized Cisco distributor, we source directly from Cisco headquarters in the name of the projects. As an officially authorized Cisco partner, we offer absolute quality products and 40% ~ 90% discount of Cisco GLP.

Packing information

H3C LS-5570S-28S-HPWR-EI-A Switches is sealed in huawei original box.

We will also pack LS-5570S-28S-HPWR-EI-A with second box before shipping.

Shipment & Payment

Our products will be send via FedEx,DHL,TNT,UPS,EMS and so on.but the buyer is responsible for customs clearance and pay tariff when the product arrived destination country.

Payment Method

T/T,Western Union, HSBC and Money Gram will be accept. Faster payment will help you to get the items earlier.



Frequently Asked Questions

Frequently asked questions, we have integrated them into a self-service Q&A. If you have other questions, please leave us a message.

Does it support modern network architectures?

Yes, it supports EVPN/VXLAN and SDN for scalable networks.

What is the minimum order quantity?

Different products have different MOQ. Let us know yourrequirements and we will try our best to meet you. Small ordersare also popular.

When can l get the quotation?

We usually quote within 24 hours after receiving your nquiry. lfyou are in a hurry, please inform us by emailor telephone. We willgive priority to your inquiry.
