Cisco Router

Cisco 4331 Series Integrated Services Router ISR4331-AXV/K9

Cisco ISR 4331 AXV Bundle with PVDM4-32, CUBE-10, IPBase, APP, SEC and UC licenses.

Product Specification:
  • Place of Origin : USA
  • Brand Name : CISCO
  • Certification : FCC
  • Model Number : ISR4331-AXV/K9
  • Minimum Order Quantity : 1/unit
  • Delivery Time : 3 days
Inquiry Now
Product Details



ISR4331-AXV/K9 is the Cisco ISR 4331 AXV Bundle with PVDM4-32, CUBE-10, IPBase, APP, SEC

and UC licenses. Cisco 4331 Integrated Services Router delivers 100 Mbps to 300 Mbps aggregate

throughput and offers one Enhanced service-module (SM-X) slot, which supports for both single- and

double-wide service modules provides flexibility in deployment options.





 Specification



Cisco ISR4331-AXV/K9 Specification

Product Number

ISR4331-AXV/K9

Product Description

Cisco ISR 4331 AXV Bundle with PVDM4-32, CUBE-10, IPBase, APP, SEC and UC licenses.

Aggregate Throughput

100 Mbps to 300 Mbps

Total onboard WAN or LAN 10/100/1000 ports

3

RJ-45-based ports

2

SFP-based ports

2

Enhanced service-module slots

1

Doublewide service-module slots

0

NIM slots

2

OIR (all I/O modules)

Yes

Onboard ISC slot

1

Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM

(Combined control/services/data planes)

4 GB

Maximum memory DDR3 ECC DRAM (Combined control/services/data planes)

16 GB

Default memory DDR3 ECC DRAM (data plane)

NA

Maximum memory DDR3 ECC DRAM (data plane)

NA

Default memory DDR3 ECC DRAM (control/services plane)

NA

Maximum memory DDR3 ECC DRAM (control/services plane)

NA

Default flash memory

4 GB

Maximum flash memory

16 GB

External USB 2.0 slots (type A)

1

USB console port -type B mini (up to 115.2 kbps)

1

Serial console port - RJ45 (up to 115.2 kbps)

1

Serial auxiliary port - RJ45

(up to 115.2 kbps)

1

Power-supply options

Internal: AC and PoE

Redundant power supply

N/A

AC input voltage

100 to 240 VAC autoranging

AC input frequency

47 to 63 Hz

AC input current range, AC power supply (maximum)

3 to 1.3A

AC input surge current

60 A peak and less than 5 Arms per half cycle

Typical power (no modules) (watts)

42

Maximum power with AC power supply (watts)

250

Maximum power with PoE power supply (platform only) (watts)

530

Maximum endpoint PoE power available from PoE power supply (watts)

250



Cisco 4331 Series Integrated Services Router ISR4331-AXV/K9 is sealed in cisco original box. We

will also pack ISR4331-AXV/K9 with second box before shipping.



Our products will be send via FedEx,DHL,TNT,UPS,EMS and so on.but the buyer is responsible for

customs clearance and pay tariff when the product arrived destination country.



Shipping Methods



2-4 business days.



2-4 business days



2-4 business days



5-7 business days.



Payment Method

T/T,Western Union, HSBC and Money Gram will be accept.Faster payment will help you to get the

items earlier.
